Chapter 2—Installation
Rear View
The rear plate contains the On/Off switch, the AC power cord socket,
and various interface connectors and slots.
8
Intermec EasyCoder PF4i—User's Guide (Fingerprint version)
Provision for EasyLAN
Ethernet connection
(option)
Memory card slot
Provision for one optional
interface board
On/Off Switch
Bar code wand socket
AC Power cord socket
RS-232 serial interface
("uart1:")
USB Interface
("usb1:")
Machine label
