Chapter 3
Installation
Rear View
18
The rear plate contains the main switch, the power inlet, and various
interface connectors:
Intermec EasyCoder F2 – Installation & Operation Ed. 2
Bar Code Wand Connector
Provision for 1 – 2
Electronic Keys
Optional Interface Board
Main Switch
Mains Receptacle
RS 232C Serial Interface ("uart1:")
Memory Card Slot
USB Interface
(for future applications)
Machine Sign
