Intermec EasyCoder 501 – User's Manual
GET TO KNOW YOUR PRINTER
LED Indicator Lamps
Display Window
Keyboard
Cutter Interface Connector
Label Taken Sensor
(option)
Memory Card Adapter
(option)
Front Door
The front door can be swung open and removed
from the hinges. It can also be replaced by an
optional paper cutter unit.
Main Switch
Voltage Switch
Provision for Optional Interface Connectors
Display Contrast Adjustment
Serial Interface Connector "uart1:"
Mains Receptacle
Upper External Paper Intake
Machine Sign
Lower External Paper Intake
Continued!
4
