Cut-Off , cont.
5
Route the media through the print
mechanism and cutter. Then push it
towards the center section as far as it
will go.
7
Turn the printhead lift lever counter-
clockwise to engage the printhead.
Intermec EasyCoder PF4i—User's Guide (Fingerprint version)
Chapter 4—Media Load
6
This diagram shows the media path.
8
Adjust the position of the green edge
guide so the media is guided with a
minimum of play.
31
