Tear-Off , cont.
1
Open the side door.
3
Remove any empty core from the media
supply roll post.
Intermec EasyCoder PF4i—User's Guide (Fingerprint version)
Chapter 4—Media Load
2
Turn the printhead lift lever clockwise to
raise the printhead.
4
Fit a new roll of media on the supply
post and adjust the edge guide so
the roll becomes fl ush with the center
section.
23
