Chapter 2—Installation
Print Mechanism
The print mechanism features a high-performance thermal printhead
with quick-mount fi ttings to facilitate replacement. The thermal trans-
fer ribbon mechanism is omitted in dedicated direct thermal printing
models.
Thermal
printhead
Pressure arm
Tear bar
Platen roller
12
Ribbon rewind hub
Label stop sensor
position adjustment
(bottom sensor hidden)
Intermec EasyCoder PF4i—User's Guide (Fingerprint version)
Ribbon supply hub
Edge guide
Printhead lift lever
