Printhead Replacement, cont.
7
Connect the two cables to the replace-
ment printhead.
9
Turn the printhead lift lever counter-
clockwise so the magnet engages the
printhead bracket.
Intermec EasyCoder PF4i—User's Guide (Fingerprint version)
Chapter 11—Maintenance
8
Put back the printhead in reverse order
and check that the printhead cables run
freely.
10
Load a new supply of media (and
ribbon), as described earlier in this
manual.
105
