Special Printheads

As standard, the printer is fi tted with an 8 dots/mm (203.2 dots/inch)
thermal printhead:
8 dots/mm (203.2 dots/inch)
Media Thickness
Max 175 µm (7 mils)
170-220 µm (6.6-8.7 mils)
11.81 dots/mm (300 dots per inch)
Media Thickness
Max 175 µm (7 mils)
170-220 µm (6.6-8.7 mils)
The printhead can easily be replaced or exchanged by the operator as
described in Chapter 11.

Interface Boards

A number of interface boards are available for use with the EasyCoder
PF4i. The interface boards are either factory-fi tted or can easily be fi tted
by an authorized service technician.
The EasyCoder PF4i can accommodate one EasyLAN interface board
plus one other interface board.
EasyLAN interface boards:
• EasyLAN Ethernet interface
• EasyLAN Wireless interface
Other interface boards:
• Parallel Interface Board (IEEE 1284)
• Double Serial Interface Board
• Serial/Industrial Interface Board
Intermec EasyCoder PF4i—User's Guide (Fingerprint version)
Standard/Option
Standard
Option
Standard/Option
Option
Option
Chapter 9—Options
89
