Self-Adhesive Strip - Intermec EasyCoder PF4i User Manual

Self-Adhesive Strip

a Media Width (including liner)
Maximum:
Minimum (standard):
Min. (narrow Quick-Load): 40.0 mm (1.57 inches)
Min. (wide Quick-Load):
b Liner
The liner must not extend more than a total of 1.6 mm (0.06 inches)
outside the face material and should protrude equally on both sides.
c Media Width (excluding liner)
Maximum:
Minimum:
Media Type Setup
• Fix length strip
• Var length strip
Intermec EasyCoder PF4i—User's Guide (Fingerprint version)
Appendix B—Media Specifi cations
114.3 mm (4.50 inches)
25.0 mm (1.00 inches)
80.0 mm (3.15 inches)
112.7 mm (4.43 inches)
23.8 mm (0.94 inches)
SELF-ADHESIVE
STRIP
125
