Chapter 3
Installation
Rear View
18
The rear plate contains the On/Off switch, the AC power cord
receptacle, the voltage switch, the standard serial interface, and
various slots.
Intermec EasyCoder 501 S – Installation & Operation Ed. 1
On/Off Switch
Provision for Parallel Interface Board
Voltage Switch (115/230 VAC)
Upper External Media Slot
Display Contrast Adjustment
AC Power Cord Receptacle
RS-232 Serial Interface ("uart1:")
Machine Label
Lower External Media Slot
