Chapter 2
Installation
Rear View
10
The rear plate contains the On/Off switch, the AC power cord
receptacle, and various interface connectors and slots.
Bar Code Wand Interface
Not used
Provision for one Optional
Interface Board
On/Off Switch
AC Power Cord Receptacle
RS-232 Serial Interface
("uart1:")
Memory Card Slot
USB Interface ("usb1:")
Machine Label
Intermec EasyCoder F2 – User's Guide
