Chapter —Installation
Rear View
The rear plate contains the On/Off switch, the AC power cord socket,
and various interface connectors and slots.
Intermec EasyCoder PM4i—User's Guide (Fingerprint version)
Provision for EasyLAN
Ethernet connection
(option)
Provision for EasyLAN
Wireless antenna
(option)
Memory card slot
Provision for two optional
interface boards
On/Off Switch
Bar code wand socket
AC Power cord socket
RS-232 serial interface
("uart1:")
USB Interface
("usb1:")
Machine label
Intake slot for external
media supply
