Appendix A—Technical Data
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Print Length (max)
Media Width (min/max)
Media Width (min/max)
Media Roll Diameter
(max)
Media Roll Core Diameter
Ribbon Width (min/max)
Ribbon Roll Diameter
(outer)
Ribbon Roll Core Diam-
eter (inner)
Print Directions
Modes of Operation
Tear-Off (Straight-
through)
Cut-Off
Peel-Off (Self-strip)
Firmware
Operating System
Smooth Fonts
Built-in scaleable fonts
(std)
Bar code symbologies (std)
118
Direct Thermal and/or Thermal
Transfer
8 dots/mm (203.2 dpi)
100 to 200 mm/sec. ( 4 to 8 in./sec.)
100 to 150 mm/sec. ( 4 to 6 in./sec.)
104 mm (4.095 inches)
105.7 mm (4.161 inches
32767 dots = 409.5 cm (161.25 in)
25 to 114.3 mm (1 to 4.5 inches)
40/80 to 114.3 mm (1.57/3.15 to 4.5
inches)
213 mm (8.38 inches)
38 to 40 mm (1.5 inches) or 76 mm
(3 inches)
25 to 110 mm (1 to 4.33 inches)
65 mm (2.56 inches) equivalent to
240-300 m (787-985 ft) of ribbon
25.4 mm (1.00 inches)
4
Yes
Optional
Optional
Intermec Fingerprint v8.20
TrueDoc and TrueType fonts
15
53
Intermec EasyCoder PF4i—User's Guide (Fingerprint version)
300 dpi is
option
8 dots/mm
300 dpi
8 dots/mm
300 dpi
1
Standard edge
guide
Quick-Load
guides
Depending on
ribbon thickness
With cutter
With liner
takeup unit
Incl. Direct
Protocol
2
Unicode fonts
