Appendix B: LAN concepts and settings
To enable or disable DNS registration:
1. From the front panel, press the MENU key and select LAN > CONFIG > DNS > DYNAMIC.
2. Turn the navigation wheel
the DHCP to register the host name specified in the lan.config.dns.hostname attribute with
the DNS server.
3. Press the ENTER key.
4. Press the EXIT (LOCAL) key twice to return to the LAN CONFIG menu.
5. Select APPLY_SETTINGS > YES, and then press the ENTER key.
To set the DNS server IP addresses:
1. From the front panel, press the MENU key and select LAN > CONFIG > DNS.
2. Turn the navigation wheel
3. Press the ENTER key.
4. Turn the navigation wheel
5. Press the ENTER key.
6. Press the EXIT (LOCAL) key twice to return to the LAN CONFIG menu.
7. Select APPLY_SETTINGS > YES, and then press the ENTER key.

LAN speeds

Another characteristic of the LAN is speed. The Series 2600B negotiates with the host computer and
other LXI-compliant devices on the LAN to transmit data at the highest speed possible. LAN speeds
must be configured to match the speed of the other instruments on the network.
To set the LAN speed:
1. From the front panel, press the MENU key and select LAN > CONFIG > SPEED.
2. Turn the navigation wheel
3. Press the ENTER key.
4. Press the EXIT (LOCAL) key once to return to the previous menu.
5. Select APPLY_SETTINGS > YES, and then press the ENTER key.
B-14
Series 2600B System SourceMeter® Instrument Reference Manual
to select either ENABLE or DISABLE. DNS registration works with
to select either DNS-ADDRESS1 or DNS-ADDRESS2.
to select and enter a valid IP address for the DNS server.
to select either 10 Mbps or 100 Mbps.
2600BS-901-01 Rev. E / January 2019
