Tektronix KEITHLEY System SourceMeter 2636B Reference Manual page 511

Series 2600B System SourceMeter® Instrument Reference Manual
lan.trigger[N].ipaddress
This attribute specifies the address (in dotted-decimal format) of UDP or TCP listeners.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
ipAddress = lan.trigger[N].ipaddress
lan.trigger[N].ipaddress = "ipAddress"
ipAddress
N
Details
Sets the IP address for outgoing trigger events.
Set to "0.0.0.0" for multicast.
After changing this setting, the lan.trigger[N].connect() command must be called before
outgoing messages can be sent.
Example
lan.trigger[3].protocol = lan.TCP
lan.trigger[3].ipaddress = "192.168.1.100"
lan.trigger[3].connect()
Also see
lan.trigger[N].connect()
2600BS-901-01 Rev. E / January 2019
Affected by
Instrument reset
LAN trigger N reset
Recall setup
The LAN address for this attribute as a string in dotted decimal notation
The LAN event number (1 to 8)
(on page 11-140)
Section 11: TSP command reference
Where saved
Not saved
Set the protocol for LAN trigger 3 to be
lan.TCP when sending LAN triggers.
Use IP address "192.168.1.100" to
connect the LAN trigger.
Default value
"0.0.0.0"
11-143
