Section 11: TSP command reference
Example 1
operationRegister = status.operation.instrument.digio.trigger_overrun.LINE1 +
status.operation.instrument.digio.trigger_overrun.LINE10
status.operation.instrument.digio.trigger_overrun.enable = operationRegister
Uses constants to set bit B1 and bit B10 of the operation status digital I/O overrun enable register.
Also see
Operation Status Registers
status.operation.instrument.digio.*
status.operation.instrument.lan.*
This attribute contains the operation status LAN summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
operationRegister = status.operation.instrument.lan.condition
operationRegister = status.operation.instrument.lan.enable
operationRegister = status.operation.instrument.lan.event
operationRegister = status.operation.instrument.lan.ntr
operationRegister = status.operation.instrument.lan.ptr
status.operation.instrument.lan.enable = operationRegister
status.operation.instrument.lan.ntr = operationRegister
status.operation.instrument.lan.ptr = operationRegister
operationRegister
Details
These attributes are used to read or write to the operation status LAN summary registers. The binary
equivalent of the value indicates which register bits are set. In the binary equivalent, the least
significant bit is bit B0, and the most significant bit is bit B15. For example, if a value of
1.02600e+03 (which is 1026) is read as the value of the condition register, the binary equivalent is
0000 0100 0000 0010. This value indicates that bit B1 and bit B10 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
11-304
(on page D-9)
(on page 11-300)
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
The status of the operation status LAN summary register; a zero (0) indicates no
bits set (also send 0 to clear all bits); other values indicate various bit settings
B13 B12 B11 B10
> > > >
0 0 0 1
Series 2600B System SourceMeter® Instrument Reference Manual
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
B9 B8 B7 B6 B5
> > > >
0 0 0 0
Default value
- -
Not applicable
0
0
0
1027 (All bits set)
B4 B3 B2 B1
> > > > >
0 0 0 0 1
