Section 11: TSP command reference
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page D-1) and
register are defined in the following table.
Bit Value
Not used
B0
status.system5.NODE57
B1
status.system5.NODE58
B2
status.system5.NODE59
B3
status.system5.NODE60
B4
status.system5.NODE61
B5
status.system5.NODE62
B6
status.system5.NODE63
B7
status.system5.NODE64
B8
Not used
B9-B15
As an example, to set bit B1 of the system summary 5 enable register, set
status.system5.enable = status.system5.NODE57.
In addition to the above constants, enableRegister can be set to the numeric equivalent of the bit
to set. To set more than one bit of the register, set enableRegister to the sum of their decimal
weights. For example, to set bits B1 and B4, set enableRegister to 18 (which is the sum of 2 +
16).
Bit
Binary value
Decimal
Weights
Bit
Binary value
Decimal
Weights
Example 1
enableRegister = status.system5.NODE57 +
status.system5.NODE60
status.system2.enable = enableRegister
Example 2
-- decimal 18 = binary 0000 0000 0001 0010
enableRegister = 18
status.system5.enable = enableRegister
Also see
status.system4.*
System summary and standard event registers
11-358
Enable and transition registers
B7 B6
0/1 0/1
128 64
7 6
(2 ) (2 )
B15 B14
0/1 0/1
32,768 16,384
15 14
(2 ) (2 )
(on page 11-355)
Series 2600B System SourceMeter® Instrument Reference Manual
(on page D-19). The individual bits of this
Description
Not applicable
Bit B1 decimal value: 2
Bit B2 decimal value: 4
Bit B3 decimal value: 8
Bit B4 decimal value: 16
Bit B5 decimal value: 32
Bit B6 decimal value: 64
Bit B7 decimal value: 128
Bit B8 decimal value: 256
Not applicable
B5 B4 B3
0/1 0/1 0/1
32 16 8
5 4 3
(2 ) (2 ) (2 )
B13 B12 B11
0/1 0/1 0/1
8,192 4,096 2,048
13 12 11
(2 ) (2 ) (2 )
Uses constants to set bits B1 and B4 of
the system summary 5 enable register.
Uses a decimal value to set bits B1 and
B4 of the system summary 5 enable
register.
(on page D-7)
Status register set
B2 B1 B0
0/1 0/1 0/1
4 2 1
2 1 0
(2 ) (2 ) (2
B10 B9 B8
0/1 0/1 0/1
1,024 512 256
10 9 8
(2 ) (2 ) (2
