Section 11: TSP command reference
Also see
trigger.timer[N].clear()
trigger.timer[N].delay
trigger.timer[N].reset()
trigger.timer[N].delay
This attribute sets and reads the timer delay.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
interval = trigger.timer[N].delay
trigger.timer[N].delay = interval
interval
N
Details
Once the timer is enabled, each time the timer is triggered, it uses this delay period.
Assigning a value to this attribute is equivalent to:
trigger.timer[N].delaylist = {interval}
This creates a delay list of one value.
Reading this attribute returns the delay interval that will be used the next time the timer is triggered.
Example
trigger.timer[1].delay = 50e-6
Also see
trigger.timer[N].reset()
trigger.timer[N].delaylist
This attribute sets an array of timer intervals.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
intervals = trigger.timer[N].delaylist
trigger.timer[N].delaylist = intervals
intervals
N
11-376
Series 2600B System SourceMeter® Instrument Reference Manual
(on page 11-375)
(on page 11-376)
(on page 11-379)
Affected by
Instrument reset
Recall setup
Trigger timer N reset
Delay interval in seconds (0.5 µs to 100 ks)
Trigger timer number (1 to 8)
Set the trigger timer 1 to delay for 50 µs.
(on page 11-379)
Affected by
Instrument reset
Recall setup
Trigger timer N reset
Table of delay intervals in seconds
Trigger timer number (1 to 8)
Where saved Default value
Not saved 10e-6 (10 µs)
Where saved Default value
Not saved 10e-6 (10 µs)
