Section 11: TSP command reference
Trigger event IDs*
Event ID
smuX.trigger.SWEEPING_EVENT_ID
smuX.trigger.ARMED_EVENT_ID
smuX.trigger.SOURCE_COMPLETE_EVENT_ID
smuX.trigger.MEASURE_COMPLETE_EVENT_ID
smuX.trigger.PULSE_COMPLETE_EVENT_ID
smuX.trigger.SWEEP_COMPLETE_EVENT_ID
smuX.trigger.IDLE_EVENT_ID
digio.trigger[N].EVENT_ID
tsplink.trigger[N].EVENT_ID
lan.trigger[N].EVENT_ID
display.trigger.EVENT_ID
trigger.EVENT_ID
trigger.blender[N].EVENT_ID
trigger.timer[N].EVENT_ID
trigger.generator[N].EVENT_ID
* Use the name of the trigger event ID to set the stimulus value rather than the numeric value. Using the name
makes the code compatible for future upgrades (for example, if the numeric values must change when
enhancements are added to the instrument).
Example
smua.trigger.arm.stimulus =
trigger.timer[1].EVENT_ID
Also see
Triggering (on page 6-1)
11-254
Series 2600B System SourceMeter® Instrument Reference Manual
Event description
Occurs when the source-measure unit (SMU)
transitions from the idle state to the arm layer
of the trigger model
Occurs when the SMU moves from the arm
layer to the trigger layer of the trigger model
Occurs when the SMU completes a source
action
Occurs when the SMU completes a
measurement action
Occurs when the SMU completes a pulse
Occurs when the SMU completes a sweep
Occurs when the SMU returns to the idle state
Occurs when an edge is detected on a digital
I/O line
Occurs when an edge is detected on a
TSP-Link line
Occurs when the appropriate LXI trigger
packet is received on LAN trigger object N
Occurs when the TRIG key on the front panel
is pressed
Occurs when a *TRG command is received on
the remote interface
GPIB only: Occurs when a GET bus command
is received
USB only: Occurs when a USBTMC TRIGGER
message is received
VXI-11 only: Occurs with the VXI-11 command
device_trigger; reference the VXI-11
standard for additional details on the device
trigger operation
Occurs after a collection of events is detected
Occurs when a delay expires
Occurs when the
trigger.generator[N].assert()
function is executed
An event on trigger timer 1 causes the arm
event detector to enter the detected state.
