Trigger event IDs*
Event ID**
smuX.trigger.SWEEPING_EVENT_ID
smuX.trigger.ARMED_EVENT_ID
smuX.trigger.SOURCE_COMPLETE_EVENT_ID
smuX.trigger.MEASURE_COMPLETE_EVENT_ID
smuX.trigger.PULSE_COMPLETE_EVENT_ID
smuX.trigger.SWEEP_COMPLETE_EVENT_ID
smuX.trigger.IDLE_EVENT_ID
digio.trigger[N].EVENT_ID
tsplink.trigger[N].EVENT_ID
lan.trigger[N].EVENT_ID
display.trigger.EVENT_ID
trigger.EVENT_ID
trigger.blender[N].EVENT_ID
trigger.timer[N].EVENT_ID
trigger.generator[N].EVENT_ID
* Use the name of the trigger event ID to set a stimulus value rather than the numeric value. Using the
name makes the code compatible for future upgrades (for example, if the numeric values must change
when enhancements are added to the instrument).
** smuX can be smua for SMU Channel A or smub for SMU Channel B

Using the remote trigger model

The source-measure unit (SMU) in the Series 2600B has a remote trigger model that supports a wide
range of triggering features for source sweeps, triggered measurements, and pulse actions.
Measurements using the trigger model can be made synchronously with sourcing actions, or they can
be made asynchronously. The following figures graphically illustrate both modes of the remote trigger
model.
2600BS-901-01 Rev. E / January 2019
Event description
Occurs when the source-measure unit (SMU)
transitions from the idle state to the arm layer
of the trigger model
Occurs when the SMU moves from the arm
layer to the trigger layer of the trigger model
Occurs when the SMU completes a source
action
Occurs when the SMU completes a measure
action
Occurs when the SMU completes a pulse
Occurs when the SMU completes a sweep
Occurs when the SMU returns to the idle state
Occurs when an edge is detected on a digital
I/O line
Occurs when an edge is detected on a
TSP-Link line
Occurs when the appropriate LXI trigger
packet is received on LAN trigger object N
Occurs when the TRIG key on the front panel
is pressed
Occurs when a *TRG command is received on
the remote interface
GPIB only: Occurs when a GET bus command
is received
USB only: Occurs when a USBTMC TRIGGER
message is received
VXI-11 only: Occurs with the VXI-11 command
device_trigger; reference the VXI-11
standard for additional details on the device
trigger operation
Occurs after a collection of events is detected
Occurs when a delay expires
Occurs when the
trigger.generator[N].assert()
function is executed
