Series 2600B System SourceMeter® Instrument Reference Manual
tsplink.group
This attribute contains the group number of a TSP-Link node. This command is not available on the
2604B/2614B/2634B.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
groupNumber = tsplink.group
tsplink.group = groupNumber
groupNumber
Details
To remove the node from all groups, set the attribute value to 0.
When the node is turned off, the group number for that node changes to 0.
The master node can be assigned to any group. You can also include other nodes in the group that
includes the master. Note that any nodes that are set to 0 are automatically included in the group that
contains the master node, regardless of the group that is assigned to the master node.
Example
tsplink.group = 3
Also see
Using groups to manage nodes on a TSP-Link system
tsplink.master
This attribute reads the node number assigned to the master node. This command is not available on the
2604B/2614B/2634B.
Type TSP-Link accessible
Attribute (R) Yes
Usage
masterNodeNumber = tsplink.master
masterNodeNumber
Details
After doing a TSP-Link reset (tsplink.reset()), use this attribute to access the node number of
the master in a set of instruments connected over TSP-Link.
2600BS-901-01 Rev. E / January 2019
Affected by Where saved
Power cycle Not applicable
The group number of the TSP-Link node (0 to 64)
Assign the instrument to TSP-Link group number 3.
Affected by
Not applicable
The node number of the master node
Section 11: TSP command reference
Default value
0
(on page 10-62)
Where saved Default value
Not applicable Not applicable
11-383
