status.measurement.voltage_limit.*
This attribute contains the measurement event voltage limit summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
measurementRegister = status.measurement.voltage_limit.condition
measurementRegister = status.measurement.voltage_limit.enable
measurementRegister = status.measurement.voltage_limit.event
measurementRegister = status.measurement.voltage_limit.ntr
measurementRegister = status.measurement.voltage_limit.ptr
status.measurement.voltage_limit.enable = measurementRegister
status.measurement.voltage_limit.ntr = measurementRegister
status.measurement.voltage_limit.ptr = measurementRegister
measurementRegister
Details
These attributes read or write to the measurement event voltage limit summary registers. Reading a
status register returns a value. The binary equivalent of the returned value indicates which register
bits are set. The least significant bit of the binary number is bit B0, and the most significant bit is bit
B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page D-1) and
register are defined in the following table.
Bit Value
B0 Not used
B1 status.measurement.voltage_limit.SMUA
B2 status.measurement.voltage_limit.SMUB
B3-B15 Not used
2600BS-901-01 Rev. E / January 2019
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
The status of the measurement voltage limit summary register; a zero (0)
indicates no bits set (also send 0 to clear all bits); other decimal values
indicate various bit settings
Enable and transition registers
Section 11: TSP command reference
Default value
- -
Not applicable
0
0
0
Models 2601B/2611B/2635B: 2 (All bits set)
Models
2602B/2604B/2612B/2614B/2634B/2636B: 6
(All bits set)
Status register set
(on page D-19). The individual bits of this
Description
Not applicable.
Set bit indicates the enabled VLMT bit for the
SMU A measurement register is set.
Bit B1 decimal value: 2
Binary value: 0000 0010
This bit is only available on Models
2602B/2604B/2612B/2614B/2634B/2636B. Set
bit indicates the enabled VLMT bit for the SMU
B measurement register is set.
Bit B2 decimal value: 4
Binary value: 0000 0100
Not applicable.
