Tektronix KEITHLEY System SourceMeter 2636B Reference Manual page 501

Series 2600B System SourceMeter® Instrument Reference Manual
lan.status.dns.name
This attribute contains the present DNS fully qualified host name.
Type TSP-Link accessible
Attribute (R) Yes
Usage
hostName = lan.status.dns.name
hostName
Details
A fully qualified domain name (FQDN), sometimes referred to as an absolute domain name, is a
domain name that specifies its exact location in the tree hierarchy of the Domain Name System
(DNS).
A FQDN is the complete domain name for a specific computer or host on the LAN. The FQDN
consists of two parts: the host name and the domain name.
If the DNS host name for an instrument is not found, this attribute stores the IP address in dotted
decimal notation.
Example
print(lan.status.dns.name)
Also see
lan.config.dns.address[N]
lan.config.dns.hostname
lan.status.duplex
This attribute contains the duplex mode presently in use by the LAN interface.
Type TSP-Link accessible
Attribute (R) Yes
Usage
duplex = lan.status.duplex
duplex
Example
print(lan.status.duplex)
Also see
None
2600BS-901-01 Rev. E / January 2019
Affected by
Not applicable
Fully qualified DNS host name that can be used to connect to the instrument
Outputs the dynamic DNS host name.
(on page 11-121)
(on page 11-123)
Affected by
Not applicable
LAN duplex setting can be one of the following values:

0 or lan.HALF: half-duplex operation

1 or lan.FULL: full-duplex operation
Outputs the present LAN duplex mode, such as:
1.00000e+00
Section 11: TSP command reference
Where saved Default value
Not applicable Not applicable
Where saved Default value
Not applicable Not applicable
11-133
