Section 11: TSP command reference
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page D-1) and
register are defined in the following table.
Bit Value
status.MEASUREMENT_SUMMARY_BIT
B0
status.MSB
status.SYSTEM_SUMMARY_BIT
B1
status.SSB
status.ERROR_AVAILABLE
B2
status.EAV
status.QUESTIONABLE_SUMMARY_BIT
B3
status.QSB
status.MESSAGE_AVAILABLE
B4
status.MAV
status.EVENT_SUMMARY_BIT
B5
status.ESB
Not used
B6
status.OPERATION_SUMMARY_BIT
B7
status.OSB
As an example, to set bit B0 of the service request enable register, set status.request_enable =
status.MSB.
In addition to the above values, requestSRQEnableRegister can be set to the numeric equivalent
of the bit to set. To set more than one bit of the register, set requestSRQEnableRegister to the
sum of their decimal weights. For example, to set bits B0 and B7, set
requestSRQEnableRegister to 129 (1 + 128).
Bit
Binary value
Decimal
Weights
Example 1
requestSRQEnableRegister = status.MSB +
status.OSB
status.request_enable = requestSRQEnableRegister
11-342
Series 2600B System SourceMeter® Instrument Reference Manual
Enable and transition registers
B7 B6 B5
0/1 0/1 0/1
128 64 32
7 6 5
(2 ) (2 ) (2 )
(on page D-19). The individual bits of this
Description
Set summary bit indicates that an enabled event in
the Measurement Event Register has occurred.
Bit B0 decimal value: 1
This bit is only available on Models
2601B/2602B/2611B/2612B/2635B/2636B. Set
summary bit indicates that an enabled event in the
System Summary Register has occurred.
Bit B1 decimal value: 2
Set summary bit indicates that an error or status
message is present in the error queue.
Bit B2 decimal value: 4
Set summary bit indicates that an enabled event in
the Questionable Status Register has occurred.
Bit B3 decimal value: 8
Set summary bit indicates that a response message
is present in the output queue.
Bit B4 decimal value: 16
Set summary bit indicates that an enabled event in
the Standard Event Status Register has occurred.
Bit B5 decimal value: 32
Not applicable
Set summary bit indicates that an enabled event in
the Operation Status Register has occurred.
Bit B7 decimal value: 128
B4 B3 B2
0/1 0/1 0/1
16 8 4
4 3 2
(2 ) (2 ) (2 )
Uses constants to set the MSB and OSB
bits of the service request (SRQ) enable
register.
2600BS-901-01 Rev. E / January 2019
Status register set
B1 B0
0/1 0/1
2 1
1 0
(2 ) (2 )
