Section 11: TSP command reference
Bit Value
status.system4.NODE46
B4
status.system4.NODE47
B5
status.system4.NODE48
B6
status.system4.NODE49
B7
status.system4.NODE50
B8
status.system4.NODE51
B9
status.system4.NODE52
B10
status.system4.NODE53
B11
status.system4.NODE54
B12
status.system4.NODE55
B13
status.system4.NODE56
B14
Not used
B15
As an example, to set bit B0 of the system summary 4 enable register, set
status.system4.enable = status.system4.enable.EXT.
In addition to the above constants, enableRegister can be set to the numeric equivalent of the bit
to set. To set more than one bit of the register, set enableRegister to the sum of their decimal
weights. For example, to set bits B11 and B14, set enableRegister to 18,432 (which is the sum of
2,048 + 16,384).
Bit
Binary value
Decimal
Weights
Bit
Binary value
Decimal
Weights
Example 1
enableRegister = status.system4.NODE53 + status.system4.NODE56
status.system2.enable = enableRegister
Uses constants to set bit B11 and bit B14 of the system summary 4 enable register.
Example 2
-- decimal 18432 = binary 0100 1000 0000 0000
enableRegister = 18432
status.system4.enable = enableRegister
Uses a decimal value to set bit B11 and bit B14 of the system summary 4 enable register.
11-356
Series 2600B System SourceMeter® Instrument Reference Manual
B7 B6 B5
0/1 0/1 0/1
128 64 32
7 6 5
(2 ) (2 ) (2 )
B15 B14 B13
0/1 0/1 0/1
32,768 16,384 8,192
15 14 13
(2 ) (2 ) (2 )
Description
Bit B4 decimal value: 16
Bit B5 decimal value: 32
Bit B6 decimal value: 64
Bit B7 decimal value: 128
Bit B8 decimal value: 256
Bit B9 decimal value: 512
Bit B10 decimal value: 1,024
Bit B11 decimal value: 2,048
Bit B12 decimal value: 4,096
Bit B13 decimal value: 8,192
Bit B14 decimal value: 16,384
Not applicable
B4 B3 B2
0/1 0/1 0/1
16 8 4
4 3 2
(2 ) (2 ) (2 )
B12 B11 B10
0/1 0/1 0/1
4,096 2,048 1,024
12 11 10
(2 ) (2 ) (2 )
2600BS-901-01 Rev. E / January 2019
B1 B0
0/1 0/1
2 1
1 0
(2 ) (2 )
B9 B8
0/1 0/1
512 256
9 8
(2 ) (2 )
