Series 2600B System SourceMeter® Instrument Reference Manual

Capabilities and features

All Series 2600B System SourceMeter
•
4.5, 5.5, or 6.5 digit display resolution
•
Resistance and power measurement functions
•
Four-quadrant sink or source operation
•
Contact check function (not available on the Models 2604B, 2614B, and 2634B)
•
High-capacitance mode for load impedance up to 50 µF (microfarads)
•
Linear, logarithmic, and custom sweeping and pulsing
•
Filtering to reduce reading noise
•
Trigger model supports extensive triggering and synchronization schemes at hardware speeds
•
Internal memory stores five user setup options
•
Dedicated reading buffers that can each store and recall over 140,000 measurements; additional
dynamic reading buffers can be created
•
USB flash drive access for saving data buffers, test scripts, and user setups
•
Digital I/O port: Allows the Series 2600B to control other devices (digital I/O lines not available on
the Models 2604B, 2614B, and 2634B)
•
Web-based characterization tool that provides easy access to data gathering, sweeping, and
pulsing features
•
®
LXI version 1.4 Core 2011 compliance
•
Embedded TSP scripting engine accessible from any host interface; responds to high-speed test
scripts comprised of instrument control commands
•
TSP-Link
each other; advanced Test Script Processor (TSP
script execution across the TSP-Link network (not available on the 2604B, 2614B, and 2634B)
•
Supports IEEE-488 (GPIB), RS-232, Universal Serial Bus (USB), and ethernet local area network
(LAN) connections
Model-specific capabilities
Additional source and measure features:
•
Model 2601B/2602B/2604B System SourceMeter

Source ±DC voltage from 5 µV to 40.4 V

Source ±DC current from 100 pA to 3.03 A

Source ±pulse current up to 10 A

Measure ±pulse current up to 10 A

Measure ±DC voltage from 100 nV to 40.8 V

Measure ±DC current from 100 fA to 3.06 A
•
Model 2611B/2612B/2614B System SourceMeter

Source ±DC voltage from 5 µV to 202 V

Source ±DC current from 2 pA to 1.515 A

Source ±pulse current up to 10 A

Measure ±pulse current up to 10 A

Measure ±DC voltage from 100 nV to 204 V

Measure ±DC current from 100 fA to 1.53 A
2600BS-901-01 Rev. E / January 2019
®
expansion bus that allows TSP-enabled instruments to trigger and communicate with
®
instruments have the following features:
®
) scripting engine features enable parallel
®
instruments:
®
instruments:
