Section 11: TSP command reference
Details
These attributes are used to read or write to the standard event status registers. Reading a status
register returns a value. The binary equivalent of the returned value indicates which register bits are
set. The least significant bit of the binary number is bit B0, and the most significant bit is bit B15. For
example, if a value of 1.29000e+02 (which is 129) is read as the value of the condition register, the
binary equivalent is 0000 0000 1000 0001. This value indicates that bit B0 and bit B7 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page D-1) and
register are defined in the following table.
Bit Value
status.standard.OPERATION_COMPLETE
B0
status.standard.OPC
Not used
B1
status.standard.QUERY_ERROR
B2
status.standard.QYE
status.standard.DEVICE_DEPENDENT_ERROR
B3
status.standard.DDE
status.standard.EXECUTION_ERROR
B4

status.standard.EXE

status.standard.COMMAND_ERROR
B5
status.standard.CME
11-346
B13 B12 B11 B10
> > > >
0 0 0 0
Enable and transition registers
Series 2600B System SourceMeter® Instrument Reference Manual
B9 B8 B7 B6
> > >
0 0 1
(on page D-19). The individual bits of this
Description
Set bit indicates that all pending selected
instrument operations are completed and the
instrument is ready to accept new
commands. The bit is set in response to an
*OPC command. The opc() function can be
used in place of the *OPC command.
Bit B0 decimal value: 1
Not applicable
Set bit indicates that you attempted to read
data from an empty Output Queue.
Bit B2 decimal value: 4
Set bit indicates that an instrument operation
did not execute properly due to some internal
condition.
Bit B3 decimal value: 8
Set bit indicates that the instrument detected
an error while trying to execute a command.
Bit B4 decimal value: 16
Set bit indicates that a command error has
occurred. Command errors include:
IEEE Std 488.2 syntax error: Instrument
received a message that does not follow the
defined syntax of the IEEE Std 488.2
standard.
Semantic error: Instrument received a
command that was misspelled or received an
optional IEEE Std 488.2 command that is not
implemented.
GET error: The instrument received a Group
Execute Trigger (GET) inside a program
message.
Bit B5 decimal value: 32
B5 B4 B3 B2
> > > > >
0 0 0 0 0
Status register set
2600BS-901-01 Rev. E / January 2019
B1 B0
> *
0 1
