Sourcing And Measuring; Basic Operation; Operation Overview - Tektronix KEITHLEY System SourceMeter 2636B Reference Manual

In this section:

Basic operation ........................................................................ 4-1

DUT test connections ............................................................. 4-27
DUT connection settings ........................................................ 4-52
Range .................................................................................... 4-57
Digits ...................................................................................... 4-62
Speed ..................................................................................... 4-63
Sweep operation .................................................................... 4-65
Relative offset ........................................................................ 4-77
Filters ..................................................................................... 4-80
High-capacitance mode ......................................................... 4-83
Basic operation
For the Models 2611B, 2612B, 2614B, 2634B, 2635B, and 2636B, hazardous voltages may be
present on all output and guard terminals. To prevent electrical shock that could cause injury
or death, never make or break connections to the Series 2600B while the instrument is
powered on. Turn off the equipment from the front panel or disconnect the main power cord
from the rear of the Series 2600B before handling cables. Putting the equipment into standby
does not guarantee that the outputs are powered off if a hardware or software fault occurs.

Operation overview

Before you begin any of the following front panel procedures, make sure that you exit out of the
menu structure. Press the EXIT (LOCAL) key as many times as needed to return to the main
display.
