Section 11: TSP command reference
Bit Value
status.MEASUREMENT_SUMMARY_BIT
B0
status.MSB
status.SYSTEM_SUMMARY_BIT
B1
status.SSB
status.ERROR_AVAILABLE
B2
status.EAV
status.QUESTIONABLE_SUMMARY_BIT
B3
status.QSB
status.MESSAGE_AVAILABLE
B4
status.MAV
status.EVENT_SUMMARY_BIT
B5
status.ESB
Not used
B6
status.OPERATION_SUMMARY_BIT
B7
status.OSB
In addition to the above constants, requestEventRegister can be set to the decimal equivalent of
the bits set. When more than one bit of the register is set, requestEventRegister contains the
sum of their decimal weights. For example, if 129 is returned, bits B0 and B7 are set (1 + 128).
Bit

Binary value

Decimal

Weights

Example
requestEventRegister = status.request_event
print(requestEventRegister)
Also see
status.condition
status.system.*
Status byte and service request (SRQ)
11-344
B7 B6
0/1 0/1
128 64
7 6
(2 ) (2 )
(on page 11-277)
(on page 11-348)
(on page D-15)
Series 2600B System SourceMeter® Instrument Reference Manual
Description
Set summary bit indicates that an enabled event in
the Measurement Event Register has occurred.
Bit B0 decimal value: 1
This bit is only available on Models
2601B/2602B/2611B/2612B/2635B/2636B. Set
summary bit indicates that an enabled event in the
System Summary Register has occurred.
Bit B1 decimal value: 2
Set summary bit indicates that an error or status
message is present in the error queue.
Bit B2 decimal value: 4
Set summary bit indicates that an enabled event in
the Questionable Status Register has occurred.
Bit B3 decimal value: 8
Set summary bit indicates that a response message
is present in the output queue.
Bit B4 decimal value: 16
Set summary bit indicates that an enabled event in
the Standard Event Status Register has occurred.
Bit B5 decimal value: 32
Not applicable
Set summary bit indicates that an enabled event in
the Operation Status Register has occurred.
Bit B7 decimal value: 128
B5 B4 B3
0/1 0/1 0/1
32 16 8
5 4 3
(2 ) (2 ) (2 )
Reads the status request event register.
Sample output:
1.29000e+02
Converting this output (129) to its binary
equivalent yields 1000 0001.
Therefore, this output indicates that the set bits of
the status request event register are presently B0
(MSB) and B7 (OSB).
B2 B1 B0
0/1 0/1 0/1
4 2 1
2 1 0
(2 ) (2 ) (2
