Series 2600B System SourceMeter® Instrument Reference Manual
ConfigPulseVMeasureISweepLin()
This KIPulse factory script function configures a voltage pulse train with a current measurement at each point.
Type TSP-Link accessible
Function No
Usage
f, msg = ConfigPulseVMeasureISweepLin(smu, bias, start, stop, limit, ton, toff, points,
buffer, tag, sync_in, sync_out, sync_in_timeout, sync_in_abort)
f, msg = ConfigPulseVMeasureISweepLin(smu, bias, start, stop, limit, ton, toff, points,
buffer, tag, sync_in, sync_out, sync_in_timeout)
f, msg = ConfigPulseVMeasureISweepLin(smu, bias, start, stop, limit, ton, toff, points,
buffer, tag, sync_in, sync_out)
f, msg = ConfigPulseVMeasureISweepLin(smu, bias, start, stop, limit, ton, toff, points,
buffer, tag, sync_in)
f, msg = ConfigPulseVMeasureISweepLin(smu, bias, start, stop, limit, ton, toff, points,
buffer, tag)
f
msg
smu
bias
start
stop
limit
ton
toff
points
buffer
tag
sync_in
sync_out
sync_in_timeout
sync_in_abort
2600BS-901-01 Rev. E / January 2019
Affected by
A Boolean flag; this flag is true when the pulse was successfully configured,
false when errors were encountered
A string message; if the f flag is false, msg contains an error message; if it is
true, msg contains a string indicating successful configuration
Instrument channel (for example, smua refers to SMU channel A)
Bias level in volts
Pulse sweep start level in volts
Pulse sweep stop level in volts
Current limit (for example, compliance) in amperes
Pulse on time in seconds
Pulse off time in seconds
Number of pulse-measure cycles
Reading buffer where pulsed measurements will be stored; if this is nil when the
function is called, no measurements will be made when the pulse train is initiated
Numeric identifier to be assigned to the defined pulse train
Defines a digital I/O trigger input line; if programmed, the pulse train will wait for a
trigger input before executing each pulse
Defines a digital I/O trigger output line; if programmed, the pulse train will generate a
trigger output immediately before the start of ton
Specifies the length of time (in seconds) to wait for input trigger; default value is 10 s
Specifies whether or not to abort pulse if input trigger is not received; if pulse aborts
because of a missed trigger, a timer timeout message is returned; true or false
Section 11: TSP command reference
Where saved Default value
