Device Connections

Connect Devices

Prerequisites
The Vunit 3000 and control PC must be on the same network segment.

Operating Procedure

Step 1 Double click the BCTools shortcut icon
Step 2 In the popup window, select the network card that is installed on the control PC.
Figure 3-1 Select network card
Notes:
If only one network card can be connected to the control PC, there is no need to set

the network card.
You can also open the network card selection window by clicking Network Card at

the top right corner.
Step 3 Click OK to complete the connected network card settings.
www.novastar.tech
Vunit 3000 Professional Control Processor User Manual
to run the control end.
