Configure Triggers - NovaStar Vunit 3000 User Manual

Figure 5-22 Timeline tasks
Step 9 Click in the column of Action and to expand the menu pane. The options include Start,
Pause and Stop.
Other operations:
: Edit the selected timeline task.

: Copy the selected timeline task as a new task.

: Delete the selected timeline task.


Configure Triggers

The Vunit 3000 supports the conditional and scheduled triggers.
Conditional trigger: Configure the trigger condition. When the trigger condition is met,

the system will automatically execute the added events in order.
Scheduled trigger: Configure the execution time. When the set time is reached, the

system will automatically execute the added events in order.
On the Central Control Configuration page, click Triggers to enter the trigger
configuration page.
www.novastar.tech
Vunit 3000 Professional Control Processor User Manual
43
