On the main menu screen, rotate the knob to select Firmware Version and press the knob
to show the relevant information.
Figure 2-6 Firmware version

2.2.4 Advanced Settings

The advanced settings allow you to set the serial port, I/O port, IR, device update, factory
reset and USB import/export.
2.2.4.1

Serial Port Settings

Step 1 On the main menu screen, rotate the knob to select Advanced Settings and press the knob
to enter the advanced settings screen.
Step 2 On the advanced settings screen, rotate the knob to select Serial Port and press the knob
to enter the serial port settings screen.
Figure 2-7 Serial port settings
Mode: View the work mode of the serial port. The supported options include COM Mode

and Modbus-ASCII Mode. The mode can be only read from the device and cannot be
set on the screen.
Slot No.: Select the slot number of the corresponding card where the COM port is

located.
CTRL: Main control card
