Step 3 Select the desired protocol. The supported options include Serial Port, I/O Port and
Ethernet Port.
Serial Port: Receive the serial command sent by the trigger end. You need to configure

the slot number of the serial port, channel number of the corresponding card where the
serial port is located, protocol type of the trigger command and received command
information.
I/O Port: Receive the high and low level signals sent by the trigger end. You need to

configure the slot number of the I/O port, channel number of the corresponding card
where the I/O port is located and received command information.
Ethernet Port: Receive the network command sent by the trigger end. You need to

configure the slot number of the Ethernet port, transmission protocol, IP address of the
trigger end, communication port number, protocol type of the trigger command and
received command information.
Step 4 (Optional) Set whether the command is triggered by a threshold.
If the command is trigger by a threshold, toggle the switch to on next to Threshold.
1.
Enter the received command in the text box next to Receive. The variables in the
2.
command must be replaced with #.
Step 5 Configure the command processing information.
Select the command processing type. The supported options include Events, Preset and
1.
Timeline.
Select the desired event or preset from the event list or preset list.
2.
Click Add to add the selected event or preset to the command list.
3.
In the command list, select an event or preset and click Up or Down to adjust the
4.
sequence of the selected event or preset.
Click Delete to delete the selected event or preset.
−
Click Clear to clear all the selected events or presets.
−
If the command processing type is set to Timeline, you need to set the control mode of
5.
the timeline for the third party. The supported options include Start, Pause and Stop.
Step 6 Enter the detailed descriptions for the added trigger.
Step 7 Click OK to complete the adding.
