- Page 1 VX16s All-in-One Controller V1.0.0 User Manual...
-
Page 2: Change History
VX16s All-in-One Controller User Manual Change History Document Version Firmware Version Release Date Description V1.0.0 V1.0.0.0 2020-06-16 First release www.novastar.tech... -
Page 3: Table Of Contents
VX16s All-in-One Controller User Manual Contents Change History ............................i 1 Overview ............................. 1 2 Appearance ............................2 Front Panel ............................ 2 Rear Panel ............................ 3 3 Applications ............................5 4 Home Screen ............................6 5 Menu Operations ..........................8 Screen Brightness ......................... - Page 4 VX16s All-in-One Controller User Manual A.1 For a Single VX16s Unit ......................24 A.2 For Multiple VX16s Units ......................24 A.3 Notes ............................25 www.novastar.tech...
-
Page 5: Overview
The VX16s supports a variety of video signals, Ultra HD 4K×2K@60Hz image processing and sending capabilities, as well as up to 10,400,000 pixels. Thanks to its powerful image processing and sending capabilities, the VX16s can be widely used in applications such as stage control systems, conferences, events, exhibitions, high-end rental and fine-pitch displays. -
Page 6: Appearance
VX16s All-in-One Controller User Manual Appearance Front Panel Type Description Power switch Power on or power off the device. USB (Type-B) Connect to the control PC for debugging. Input source On the layer editing screen, press the button to switch the input source for the layer;... -
Page 7: Rear Panel
VX16s All-in-One Controller User Manual Rear Panel Inputs Connector Description Max. input resolution: Up to 1920×1080@60Hz 3G-SDI Support for interlaced signal input and deinterlacing processing DOES NOT support input resolution settings. Single link DVI connector, with max. input resolution up to 1920 ×... - Page 8 VX16s All-in-One Controller User Manual Support for resolution of 1920×1080@60Hz Control Connector Description ETHERNET Connect to the control PC for communication. Connect to the network. USB 2.0 (Type-B): - Connect to the PC for debugging. - Input connector to link another device ...
-
Page 9: Applications
VX16s All-in-One Controller User Manual Applications Note: This product can only be worked horizontally. Wall mounting is not permitted. www.novastar.tech... -
Page 10: Home Screen
The layer is active and the layer input source name and resolution are displayed. The layer is inactive. The VX16s is in video controller mode and this Ethernet port is connected. This Ethernet port is not connected. This Ethernet port is connected and serves as the backup output port. - Page 11 The BKG function is turned on. The BKG function is turned off. Communication The VX16s is communicating with the control PC via USB. The VX16s is communicating with the control PC via LAN. The VX16s is not connected to the control PC.
-
Page 12: Menu Operations
VX16s All-in-One Controller User Manual Menu Operations Operating Instructions: Knob: On the home screen, press the knob to enter the main menu screen. On the main menu screen, rotate the knob to select a menu item, and press the knob to confirm the selection or enter the submenu. -
Page 13: Loading Rcfgx Files
After the LED screen is powered on, if a cabinet or the entire LED screen is not lit, you can load the receiving card configuration files (namely RCFGx files) that have been configured in NovaLCT to the VX16s. Step 1 (Optional) After you have configured the screen in NovaLCT, click Save to File under the Receiving Card tab to save the configuration file to the PC. - Page 14 Figure 5-4 Importing controller cabinet configuration files Step 3 Click Add Configuration File to select the target file (*.rcfgx/*.rcfg) from your PC, and then click Open. Step 4 Click Save the Change to HW to send the configuration files to the VX16s. www.novastar.tech...
-
Page 15: Save To Rv Card
VX16s All-in-One Controller User Manual Figure 5-5 Saving changes to the VX16s Note: The configuration files for irregular cabinets are not supported. 5.2.3 Save to RV Card You can send and save the screen configuration to the receiving card. The configuration data will not be lost after the VX16s is powered off. -
Page 16: More Settings
Note: The receiving cards of the screen must support the Mapping function. You can check the types of receiving cards on NovaStar’s official website (www.novastar.tech). LED Screen Color You can adjust the screen color and the adjustment result will be displayed on the LED screen in real time. -
Page 17: Layer Settings
VX16s All-in-One Controller User Manual Layer Settings Step 1 Press the knob to enter the main menu screen. Step 2 Rotate the knob to select Layer Settings and press the knob to enter the layer settings screen where you can set the following. -
Page 18: Input Settings
VX16s All-in-One Controller User Manual Figure 5-10 Layer parameter description Figure 5-11 Input crop Input Settings 5.4.1 Input Source Selection The supported input sources include HDMI, SDI and DVI. Rotate the knob to select the desired input source and press the knob to enter the input source resolution setting screen. -
Page 19: Input Resolution Settings
VX16s All-in-One Controller User Manual Figure 5-12 Input source selection 5.4.2 Input Resolution Settings The following two methods are provided to set the input resolution: Standard resolution Custom resolution Figure 5-13 Choosing a resolution setting method Note: The SDI input source does not support resolution settings. -
Page 20: Dvi Mosaic
VX16s All-in-One Controller User Manual Standard Resolution HDMI 2.0 SL-DVI √ √ 1280×720@(23.98/24/25/29.97/30/48/50/59.94/60)Hz √ √ 1280×1024@(48/50/59.94/60/75/85)Hz √ 1364×768@(50/59.94/60)Hz √ 1366×768@(50/59.94/60)Hz √ √ 1440×900@(60/75/85)Hz √ √ 1600×1200@(48/50/59.94/60)Hz √ √ 1680×1050@60Hz √ √ 1920×1080@(23.98/24/25/29.97/30/48/50/59.94/60)Hz √ √ 1920×1200@(50/59.94/60)Hz √ √ 2048×1080@(30/48/50/59.94/60)Hz √... -
Page 21: Rgb Limited To Rgb Full
5.4.4 RGB Limited to RGB Full The VX16s can automatically convert the color space of the video source from RGB limited to RGB full, allowing for more accurate video processing. -
Page 22: Preset Settings
Reset the image color parameters to the factory defaults. Preset Settings The VX16s supports 10 presets. Users can save, load and clear the configured presets. Step 1 Rotate the knob to select Preset Settings and press the knob to enter the preset settings screen. -
Page 23: Image Mosaic
2160 Advanced Settings 5.8.1 Hot Backup You can set the VX16s as the primary device or backup device. The data flow patterns in both the modes are the same. Set as Primary: The icon of the target Ethernet port on the home screen is highlighted. -
Page 24: Advanced Functions
5.8.4 Advanced Functions Advanced functions include 3D mode and self-test settings. 5.8.4.1 3D Mode The VX16s can work with the EMT200 3D emitter and 3D glasses to provide you with 3D visual experience. Notes Turning on 3D mode halves the device output capacity. -
Page 25: Output Frame Rate
5.10 Communication Settings 5.10.1 Communication Mode The VX16s is connected to the PC via USB port and Ethernet port at the same time. The communication modes include USB Preferred and LAN Preferred. Figure 5-20 Communication mode ... -
Page 26: Network Settings
VX16s All-in-One Controller User Manual When LAN Preferred is selected, the VX16s communicates with the PC via Ethernet port by preference. 5.10.2 Network Settings The methods for network settings include Manual and Auto. Manual: Set the device IP address and subnet mask manually. -
Page 27: Specifications
VX16s All-in-One Controller User Manual Specifications Power connector 100–240V~, 50/60Hz, 2.1A Electrical Specifications Power consumption 70 W Temperature 0° C to 50° C Operating Environment Humidity 20% RH to 85% RH, non-condensing –20º C to +60º C Temperature Storage Environment Humidity 10% RH–85% RH, non-condensing... -
Page 28: A Instructions For The 3D Function
Step 1 Select a 3D video source and connect it to the DVI or HDMI connectors of all the VX16s units. Step 2 Connect all VX16s units to the LED screen via Ethernet cables, and connect the EMT200 to one of the units via an Ethernet cable. - Page 29 Step 10 Turn on the 3D mode and wear your 3D glasses to enjoy the 3D effect. A.3 Notes 1. Turning on the 3D mode halves the loading capacity of each Ethernet port and the VX16s unit. 2. It is recommended you stay at most 3 meters away from the EMT200 when using the 3D glasses.
