Figure 2-2 Backplane connector status
Descriptions for the connector status:
Green: The connector is connected normally.

White: The connector is not connected.

The empty card slot indicates that no card is installed.

Menu Functions

Press the knob to enter the main menu screen.
Figure 2-3 Main menu

2.2.1 Return to Home Screen

You can set the period when the system stays at the current screen before returning to the
homepage automatically when no operation is performed.
On the main menu screen, select Return to Home Screen and press the knob to confirm.
Rotate the knob to select the desired duration and press the knob to confirm. The value
ranges from 60s to 3600s.
