Baud Rate: You can customize the baud rate value, which ranges from 3 to 1000 Kbps

and defaults to 250. The unit is Kbps.
Mode: The supported options include Normal (default) and Loopback.

No.: The value is an integer from 0 (default) to 15.

Enable: The supported options include Enable and Disable (default).

Mode: The supported options include List and Mask.

When you set the mode to List, the values of List-High and List-Low need to be set.
−
When you set the mode to Mask, the values of Mask-High and Mask-Low need to
−
be set.

Configure Matrixes

The Vunit 3000 is equipped with the VIT_4xHDMI2.0 IN + 3x HDMI2.0 OUT card that can
function as a small matrix with 4 inputs and 3 outputs. On the Matrix page, you can set the
relationship between the input and output. The one-to-one and one-to-many relationships
are supported.

5.3.1 Set Input and Output Relationships

Step 1 Click the Central Control Configuration tab to enter the corresponding page.
Step 2 Select the desired device from the device list on the left.
Step 3 Click the Matrix tab to enter the matrix configuration page.
