COM-HPC-ALT User's Guide

4.3.12 SMBus

Name Pin #
SMB_CLK C86
SMB_DAT C87
SMB_ALERT# C88

4.3.13 General Purpose Input Outputs

Name Pin #
GPIO_00 A88
GPIO_01 A89
GPIO_02 A90
GPIO_03 A91
GPIO_04 A92
GPIO_05 A93
GPIO_06 A94
GPIO_07 A95
GPIO_08 A96
GPIO_09 A97
GPIO_10 A98
GPIO_11 A99
Page 26
Description
System Management Bus bidirectional clock line.
System Management Bus bidirectional data line.
System Management Bus Alert – active low input can
be used to generate an SMI# (System Management
Interrupt) or to wake the system.
Description
General purpose input / output pins. Upon a
hardware reset, these pins should be configured as
inputs.
As inputs, these pins should be able to generate an
interrupt to the Module host.
Copyright © 2023 ADLINK Technology, Inc.
I/O PU / PD Comment
I/O OD PU 2.2K The maximum capacitance on the Carrier Board shall not
3.3VSB exceed 100pF
I/O OD PU 2.2K The maximum capacitance on the Carrier Board shall not
3.3VSB exceed 100Pf
I The maximum capacitance on the Carrier Board shall not
3.3VSB exceed 100pF
I/O PU / PD Comment
I/O PU 100K
3.3VSB 3.3VSB
PICMG COM-HPC R1.0
