3.46 BatMan SMBus Voltage Select (CN82)

Table 3-53 lists the pin signals of the BatMan SMBus voltage select jumper header, which pro-
vides 3 pins in a single row with 2.00mm pitch.
Pin #
1 +V3PS
2 I2C_PM_VSEL
3 +V5P0A

3.47 Display Mode Select (CN85)

Table 3-54 lists the pin signals of the Display Mode select jumper header, which provides 3 pins
in a single row with 2.00mm pitch.
Pin #
1 +V3PS
2 DP/HDMI_SEL2
3 GND

3.48 Display Port Control Switch (SW6)

Table 3-55 lists the pin signals of the Display Port Control dip switch, which provides 4 poles, 8
pin positions with 1.27mm pitch.
Pin #
1 (off) DP_CNTRL [Default]
2 (off) DP_CNTRL [Default]
3 (off) DP_EQ [Default]
4 (off) DP_EQ [Default]

3.49 Display Port Control Switch (SW7)

Table 3-56 lists the pin signals of the Display Port Control dip switch, which provides 8 poles, 16
pin positions with 1.27mm pitch.
Pin #
1 (off) DP_ENABLE [Default]
2 (off) DP_AUTOEQ [Default]
3 (off) DP_OC_0 [Default]
4 (off) DP_OC_1 [Default]
5 (off) DP_OC_0 [Default]
6 (off) DP_OC_1 [Default]
7 (off) Not Connected [Default]
8 (off) Not Connected [Default]
NOTE: Refer to the PI3EQXDP1201 Display Port Redriver datasheet for more details.
.
Interfaces
Table 3-53: BatMan SMBus Voltage Select (CN82)
Signal
• Jumper Installed 1-2 - 3.3-volt standby source
• Jumper Installed 2-3 - 5-volt ATX source (Default)
Table 3-54: Display Mode Select (CN85)
Signal
• Jumper Installed 1-2 - HDMI B mode
• Jumper Installed 2-3 - Display Port mode (Default)
Table 3-55: Display Port Control Switch (SW6)
Signal
Table 3-56: Display Port Control Switch (SW7)
Signal
Jumper Position
Jumper Position
Pin#
8 (on) +V3P3S
7 (on) GND
6 (on) +V3P3S
5 (on) GND
Pin#
16 (on) GND
15 (on) GND
14 (on) GND
13 (on) GND
12 (on) GND
11 (on) GND
10 (on) Not Connected
9 (on) Not Connected
LEC-BASE MINI
Signal
Signal
