6.4.2 PCI Interrupt Routing Map
INT Audio xHCI
Line Controller Controller
Int0 INTA: 16 INTA: 16
Int1 INTB: 17
Int2 INTC: 18
Int3 INTD: 19
INT Line PCIe Port 1
Int0 INTA: 16
Int1 INTB: 17
Int2 INTC: 18
Int3 INTD: 19
6.5

SMBus Slave Addresses

Table 10 SMBus Slave Addresses

Device Address
DIMM A 0A0h
DIMM B 0A4h
BMC 050h
NXP 0C0h
System Resources

Table 9 PCI Interrupt Routing Map

TXE LPC
Controller #1 Controller
INTA: 16 INTA: 16
INTB: 17 INTB: 17
INTC: 18 INTC: 18
INTD: 19 INTD: 19
PCIe Port 5 PCIe Port 6
INTA: 16 INTB: 17
INTB: 17 INTC: 18
INTC: 18 INTD: 19
INTD: 19 INTA: 16
SATA SMBus
Controller Controller
INTA: 16 INTA: 16
PCIe Port 11 PCIe Port 17
INTC: 18 INTA: 16
INTD: 19 INTB: 17
INTA: 16 INTC: 18
INTB: 17 INTD: 19
AMSTX-CF Series
PCIe Port 21
INTA: 16
INTB: 17
INTC: 18
INTD: 19
