Network

* This setting is valid after restarting the transceiver.
L See the Advanced manual for details about the IP
addresses.
» SET > Network
MENU
DHCP*
Turns the DHCP function ON or OFF.
• OFF: Uses static IP addresses.
• ON: Uses the DHCP function. If a DHCP server
is in your network environment, the IP
addresses are automatically obtained.
L When this function is ON, you can check the settings
assigned by the DHCP server by touching "IP Information"
on the QUICK MENU screen.
L Confirm that a DHCP server is in a network to which the
RF deck (and the controller) is connected.
IP Address (LAN)*
Sets a static IP address.
L You cannot set the same address as "IP Address
(Controller)," "IP Address (RF Deck)," and "Default
Gateway."
L When the controller and RF deck are connected through
a network, set all of "IP Address (LAN)," "IP Address
(Controller)," and "IP Address (RF Deck)."
L When you are operating the IC-7760 using the optional
RS-BA1, "IP Address (LAN)" is used to access.
IP Address (Controller)*
Sets a static IP address.
L You cannot set the same address as "IP Address (LAN),"
"IP Address (RF Deck)," and "Default Gateway."
L When the controller and RF deck are connected through
a network, set all of "IP Address (LAN)," "IP Address
(Controller)," and "IP Address (RF Deck)."
IP Address (RF Deck)*
Sets a static IP address.
L You cannot set the same address as "IP Address (LAN),"
"IP Address (Controller)," and "Default Gateway."
L When the controller and RF deck are connected through
a network, set all of "IP Address (LAN)," "IP Address
(Controller)," and "IP Address (RF Deck)."
L To connect the controller and RF deck between different
segments, set "Connection from Different Segment" to
ON, and then set the items in the "Different Segment
Settings" menu.

Subnet Mask*

(Default: 255.255.255.0(24 bit))
Sets the subnet mask to connect to your PC or Local
Area Network (LAN), through your router.
(Default: ON)
(Default: 192.168.0.10)
(Default: 192.168.0.11)
(Default: 192.168.0.12)
8-14

Default Gateway*

Sets the Default Gateway of the IC-7760.
L A Default Gateway setting is required when:
- Remotely controlling the IC-7760.
- Using the NTP function.
- Connecting the controller and RF deck between different
segments.
Primary DNS Server*
Sets the Primary DNS Server address.
Secondary DNS Server*
If there are two DNS server addresses, sets the
secondary DNS server address.
Audio Buffer Size (via LAN)*
When the controller and RF deck are connected
through a network, selects the audio buffer size to
reduce audio interruptions.
Connection from Different Segment* (Default: OFF)
Set to "ON" to connect the controller and RF deck
between different segments.
» SET > Network > Different Segment Settings
MENU
L Displayed only when "Connection from Different
Segment" is set to "ON."
IP Address (RF Deck)*
Sets a static IP address.
L You cannot set the same address as "Default Gateway."
Subnet Mask (RF Deck)*
(Default: 255.255.255.0(24 bit))
Sets the subnet mask of the network that the RF deck
is connected to.
Default Gateway (RF Deck)*
Sets the Default Gateway of the RF deck.
Audio Buffer Size*
Selects the audio buffer size to reduce audio
interruptions.
This setting is valid only when connecting the
controller and RF deck between different segments.
8
SET MODE
(Default: . . . .)
(Default: . . . .)
(Default: . . . .)
(Default: Mid)
(Default: 192.168.100.10)
(Default: 192.168.100.1)
(Default: Mid)
8
