8
SET MODE
CW-KEY Set

Paddle Polarity

Sets the paddle dot-dash polarity to Normal or
Reverse.
• Normal: Right = dash, Left = dot
• Reverse: Right = dot, Left = dash
Key Type
Sets the key type for the [ELEC-KEY] jack on the
controller's rear panel.
• Set to Straight, Bug, or Paddle.
L When using an external Elec-keyer, select "Straight."
MIC Up/Down Keyer
Selects whether or not to use the keys on the
microphone as a CW key.
• OFF: Do not use the microphone keys as a CW key.
• ON: Use the [UP]/[DN] keys as a CW key.
L The microphone keys do not work as a "squeeze key."
L When "ON" is selected, you cannot use the function that
is assigned to each key.

Function

(Default: Normal)
MENU
Beep Level
Sets the beep output level.
L If "Beep (Confirmation)" is set to "OFF," no beeps sound.
(Default: Paddle) Beep Level Limit
Selects whether or not to limit the volume up to a
specified level.
• OFF: Does not limit the volume level.
• ON: Limits the volume level.
(Default: OFF)
Beep (Confirmation)
Turns the Confirmation beep ON or OFF.
• OFF: Turns OFF the function for silent operation.
• ON: A beep sounds when a switch is pushed or
L If "Beep Level" is set to "0%," no beep sounds.
Band Edge Beep
Selects an option for the Band Edge Beep function.
• OFF:
• ON (Default): A beep sounds when you tune out
• ON (User):
• ON (User) & TX Limit:
L If "Beep Level" is set to "0%," no beep sounds.
Beep Sound (MAIN)
Beep Sound (SUB)
Sets the audio frequency for beeps to between 500
and 2000 Hz.
Speaker MAIN/SUB Mix
Sets the audio output from the internal and external
speaker.
• OFF: Outputs the Main band's audio from the left side,
• ON: Outputs the mixed audio.
L See page 13-7 for details.
8-3
» SET > Function
the touch panel is touched.
(Default: ON (Default))
Turns OFF the function.
of, or back into the default amateur
band's frequency range.
A beep sounds when you tune out
of, or back into a user programmed
amateur band's frequency range.
A beep sounds when you tune out
of, or back into a user programmed
amateur band's frequency range.
Transmitting is inhibited outside of the
range.
and the Sub band's audio from the right side.
(Default: 50%)
(Default: ON)
(Default: ON)
(Default: 1000Hz)
(Default: 1000Hz)
(Default: OFF)
