Icom IC-7760 Addendum

Icom IC-7760 Addendum

Hide thumbs Also See for IC-7760:

Advertisement

Quick Links

Download this manual
The following features are now changed in, or added to, the IC-7760.
: New functions and/or menus have been added.
Added
: Some operations, items, and/or options that already exist have been changed.
Changed
Controller and RF deck connection ......... 1
Changed
Connection through a wireless LAN ......... 8
Added
Connecting the controller and RF deck
Changed
through a network ................................. 9
Set mode .......................................... 10
Changed
Controller and RF deck connection
Changed
• The function to connect the controller and RF deck through a wireless LAN or the Internet is added.
L A network environment with the following stable network speed is required.
- Controller ➔ RF deck:
- RF deck ➔ Controller: 10 Mbps or faster
IMPORTANT! To remotely control the IC-7760, BE SURE you comply with any local regulations.
NOTE: The controller and RF deck do not have wireless LAN capabilities. To connect to a wireless LAN, you
need a wireless LAN converter or a wireless LAN Access Point (User supplied) for the LAN port. (p. 8)
L A wireless LAN adapter for a USB port cannot be used.
• Up to 5 controllers (supplied or optional RC-7760) can be paired to one RF deck.
L Even when an RF deck is paired with 2 or more controllers, you can use only one controller at a time to operate the RF deck.
L DO NOT connect 2 or more controllers to the RF deck's [CONTROLLER].
L If the controller is paired with an RF deck other than the last RF deck it was connected to, the pairing information with the
previous RF deck is deleted.
NOTE: The controller and RF deck have different hardware versions, depending on the country of sale. If the
controller and RF deck's hardware version do not match, they cannot be connected.
INFORMATION
IC-7760 Version 1.10
5 Mbps or faster
Compatibility with SDXC cards ............ 12
Added
Partial reset .................................... 13
Changed
All reset .......................................... 13
Changed
All reset for the RF deck ..................... 13
Added
CI-V commands ................................. 14
Changed
1
V1.10

Advertisement

loading
Need help?

Need help?

Do you have a question about the IC-7760 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Icom IC-7760

Summary of Contents for Icom IC-7760

  • Page 1 - RF deck ➔ Controller: 10 Mbps or faster IMPORTANT! To remotely control the IC-7760, BE SURE you comply with any local regulations. NOTE: The controller and RF deck do not have wireless LAN capabilities. To connect to a wireless LAN, you need a wireless LAN converter or a wireless LAN Access Point (User supplied) for the LAN port.
  • Page 2 The IC-7760’s controller and RF deck connect using the IP IP Address (LAN) Controller method. The IC-7760 has 3 IP addresses described to the right, IP Address (Controller) and when you connect the controller and RF deck through a RF deck IP Address (RF Deck) network, all of 3 IP addresses are used.
  • Page 3 V1.10 Controller and RF deck connection Changed D About the Connection route and IP connection between the controller and RF deck Connecting through LAN LAN (in Same Segment): The controller and RF deck are in the same segment. L All 3 IP addresses are used for the connection. Controller IP Address (LAN) IP Address (LAN)
  • Page 4 V1.10 Controller and RF deck connection Changed D About the Connection route and IP connection between the controller and RF deck Connecting through LAN with a router Set the RF deck’s static IP address that is displayed after “Connection Route” is changed. »...
  • Page 5 V1.10 Controller and RF deck connection Changed D About the Connection route and IP connection between the controller and RF deck Connecting through the Internet Set the RF deck’s static IP address that is displayed after “Connection Route” is changed. »...
  • Page 6 V1.10 Controller and RF deck connection Changed D About the Connection route and IP connection between the controller and RF deck Connecting through the Internet VPN Internet (L2 VPN in Same Segment): The controller and RF deck are connected through the Internet by using a Layer 2 VPN (such as L2TP). L2 VPN router L2 VPN router L2 VPN router...
  • Page 7 V1.10 Controller and RF deck connection Changed D About the Connection route and IP connection between the controller and RF deck When using additional controllers Example: When connecting one controller through a network and connecting the other directly • When operating the controller connecting through a network (Controller 1), all 3 IP addresses are used for the connection.
  • Page 8 V1.10 Connection through a wireless LAN Added You can connect the controller and RF deck through a wireless LAN using a wireless LAN converter or a wireless LAN Access Point (User supplied) for LAN port. L A wireless LAN adapter for USB port cannot be used. When there is a wireless network device between the controller and RF deck, set “The Route includes Wireless LAN”...
  • Page 9 V1.10 Connecting the controller and RF deck through a network Changed NOTE: • You need to connect the controller and RF deck directly to pair them before using the transceiver for the first time. If you do not, they cannot be connected. (“The RF deck is not detected.” is displayed and blinks.) •...
  • Page 10 V1.10 Set mode Changed DNetwork • “Connection from Different Segment” and “Different Segment Settings” have been included in “Controller Connection (via LAN).” • “The Route includes Wireless LAN” is added. • “Audio Buffer Size (via LAN)” has been included in “Audio Buffer Size.” •...
  • Page 11 V1.10 Set mode Changed D Network » SET > Network > » SET > Network > MENU MENU Controller Connection (via LAN) Controller Connection (via LAN) > Port Forwarding Settings The Route includes Wireless LAN* (Default: OFF) L These settings are displayed only when “Connection Selects whether there is a wireless network device Route”...
  • Page 12 TIP: If the received audio is intermittent, select a An SDXC card up to 256GB can now be used in this longer value. transceiver. Icom has checked the compatibility with the following cards. (As of February 2025) Round Trip Time...
  • Page 13 V1.10 Partial reset All reset for the RF deck Changed Added The Antenna memory contents are not cleared, even if An All reset for the RF deck resets the items listed you perform a Partial reset. below, that are saved onto the RF deck. •...
  • Page 14 V1.10 CI-V commands Changed The following commands are changed in, or added to the conventional Command table. Cmd. Sub cmd. Data Description Cmd. Sub cmd. Data Description 05 SET > Network 05 SET > Network > Controller Connection (via LAN) > Audio Buffer Size 01 65 See p.
  • Page 15 V1.10 CI-V commands Changed • IP address setting • Codes for character entries Command: 1A 05 01 65, 01 67, 01 72, 01 74 Command: 1A 05 03 71 - Character codes— Letters and Numbers 0 X X X 0 X X X 0 X X X 0 X X X Character ASCII code Character...
