Icom IC-7760 Basic Manual page 69

» SET > Connectors > Keyboard/Mouse
MENU
Keyboard [F1]-[F8] (VOICE)
Keyboard [F1]-[F8] (KEYER)
Enables each memory (voice, keyer) transmission
using a keyboard connected to the [USB A] port on
the controller's rear panel.
Keyboard Type
Selects the keyboard language.
Keyboard Repeat Delay
Sets the repeat delay time of the keyboard.
Keyboard Repeat Rate
Sets the repeat rate of the keyboard.
Mouse Pointer Speed
Selects the mouse pointer speed.
Mouse Pointer Acceleration
Turns the mouse pointer acceleration ON or OFF.
» SET > Connectors > USB DIAL
MENU
USB DIAL Select
Selects the Sub band or Main and Sub band to
operate on the RC-28's main dial.
L When this item is set to "Only SUB," you can select
MAIN DIAL
whether changes only the Main band
frequency, or changes both the Main and Sub band
frequencies depending on which band is selected.
»
SET > Function >
MENU
MAIN DIAL Select (USB DIAL - SUB Only)
USB DIAL Auto TS
Selects the Automatic Tuning Step for the RC-28's
main dial.
When rapidly rotating the RC-28's main dial, the
tuning step is automatically changed according to the
rotation speed.
USB DIAL [TRANSMIT] Switch
Selects whether to toggle between transmit and
receive by pushing, or to transmit only while holding
the [TRANSMIT] key on the RC-28.
(Default: OFF)
(Default: OFF)
(Default: English)
(Default: 250ms)
(Default: 10.9cps)
(Default: MID)
(Default: ON)
(Default: Only SUB)
(Default: High)
(Default: Push to toggle)
8-12
» SET > Connectors > CI-V
MENU
CI-V Baud Rate
Selects the CI-V data transfer rate.
L When "Auto" is selected, the baud rate is automatically
set according to the data rate of the connected device.
CI-V Address
Sets the CI-V address in hexadecimal code.
L "B2" is the default address of the IC-7760.
CI-V Transceive
Turns the Transceive function ON or OFF.
• OFF: The status is not output.
• ON: The status is output. When you change a
setting on the transceiver, the same change
is automatically set on other connected
transceivers or receivers, and vice versa.
CI-V USB/LAN→REMOTE Transceive Address
Sets the address used to remotely control the
transceiver or receiver using the optional RS-BA1,
through the [USB B] port on the controller's rear panel
or the [LAN] port on the RF deck's rear panel.
The external equipment control signal is output from
the [REMOTE] jack on the RF deck's rear panel.
CI-V Output (for ANT)
Enables outputting the antenna controller status
(frequency and so on) from the [REMOTE] jack on the
RF deck's rear panel.
L Address "01h" is reserved.
The usable addresses are limited to 02h ~ DFh.
CI-V USB (A) Echo Back
CI-V USB (B) Echo Back
Turns the Data Echo Back function ON or OFF, when
remotely controlling the IC-7760 through the [USB B]
port on the controller's rear panel.
8
SET MODE
(Default: Auto)
(Default: B2h)
(Default: ON)
8
(Default: 00h)
(Default: OFF)
(Default: OFF)
(Default: OFF)
