» SET > Function
MENU
[SPEECH/LOCK] Switch
Selects action.
SPEECH
• SPEECH/LOCK: Pushing
the Voice Synthesizer function.
Holding down
Lock function ON or OFF.
• LOCK/SPEECH: Pushing
function ON or OFF. Holding down
SPEECH
Synthesizer function.

Lock Function

This function electronically locks
panel display* to prevent accidental changes.
* Keys and dials are also locked except for
, and .
POWER SPEECH
Memo Pad Quantity
Sets the number of memo pad channels to 5 or 10.
MAIN DIAL Auto TS
Sets the Auto Tuning Step function for
When rapidly rotating
MAIN DIAL
automatically changes according to the rotation speed.
• OFF: Auto tuning step is turned OFF.
• Low: Approximately two times faster.
• High: Approximately five times faster when the
tuning step is set to 1 kHz or smaller.
Approximately two times faster when the
tuning step is set to 5 kHz or larger.
MAIN DIAL Select (USB DIAL - SUB Only)
Selects whether
MAIN DIAL
band frequency, or changes both the Main and Sub
band frequencies, depending on which band is
selected.
L This is convenient when using the optional RC-28
remote encoder to change the Sub band frequency.
MIC Up/Down Speed
Selects the steps per second when changing
an operating frequency by holding down the
microphone's [UP]/[DN] key.
• Slow: Low speed (25 tuning steps/second)
• Fast: High speed (50 tuning steps/second)
(Default: SPEECH/LOCK)
turns ON
SPEECH
turns the
SPEECH
turns the Lock
SPEECH
turns ON the Voice
(Default: MAIN DIAL)
or the
MAIN DIAL
,
AF RF/SQL
(Default: 5)
(Default: High)
.
MAIN DIAL
, the tuning step
(Default: MAIN/SUB)
changes only the Main
(Default: Fast)
Quick RIT/∂TX Clear
Selects the operation for the RIT and ∂TX
CLEAR
functions.
• OFF: Holding down
RIT or ∂TX shift frequency.
• ON: Pushing
CLEAR
frequency.
[NOTCH] Switch (SSB)
[NOTCH] Switch (AM)
Selects the Notch function used in the SSB or AM mode.
• Auto: Only the Auto Notch function can be
used.
• Manual: Only the Manual Notch function can
be used.
• Auto/Manual: Both the Auto and Manual Notch
functions can be used.
FILTER Screen MAIN/SUB Select
(Default: Auto (by FILTER, PBT Operation))
Selects whether or not to automatically switch the IF
filter or Twin PBT settings when Main and Sub bands
are switched between each other, while displaying the
FILTER screen.
SSB/CW Synchronous Tuning
Turns the Displayed Frequency Shift function ON or
OFF. This function automatically shifts the frequency
to match the CW pitch when the operating mode is
toggled between SSB and CW.
• OFF: Turns OFF the function.
• ON: When the operating mode is changed
between SSB and CW, the operating
frequency shifts by the offset amount.
CW Normal Side
Selects the carrier point in the CW normal mode.
• LSB: Sets the carrier point to the LSB side.
• USB: Sets the carrier point to the USB side.
» SET > Function > Front Key Customize
MENU
[VOX/BK-IN]
[AUTOTUNE]
The function assignments for the
keys on the front panel can be changed.
AUTO TUNE
L See page 8-7 about the functions.
8-6
SET MODE
(Default: OFF)
for 1 second resets the
CLEAR
resets the RIT or ∂TX shift
(Default: Auto/Manual)
(Default: Auto/Manual)
(Default: OFF)
(Default: LSB)
(Default: VOX/BK-IN)
(Default: AUTOTUNE)
and
VOX/BK-IN
8
8
