8
SET MODE
Function
» SET > Function > SPLIT
MENU

SPLIT LOCK

Turns the Split Lock function ON or OFF.
The SPLIT LOCK function enables you to adjust the
transmit frequency while holding down
while the Dial Lock function is activated. To prevent
accidentally changing the receive frequency by
rotating , use both the SPLIT LOCK and Dial
MAIN DIAL
Lock functions (p. 3-9).
• OFF: Turns OFF the function.
• ON: Turns ON the function.
» SET > Function > Tuner
MENU
PTT Start
Turns the PTT Start Tuning function ON or OFF.
This function starts tuning when [PTT] is pushed, if the
operating frequency is shifted 1% or more while the
antenna tuner is ON.
<<Preset Memory Clear>>
Clears all of the internal antenna tuner's entered
memory frequencies.
Select the antenna to clear the memory between "ANT
1," "ANT 2," "ANT 3," "ANT 4," and "All."
L To clear all antenna memories, select "All."
» SET > Function
MENU
Transverter Function
Selects whether to turn ON the transverter function
or to automatically turn it ON when 2 to 15 V DC is
applied to pin 6 of [ACC 2].
Transverter Offset
Sets the offset frequency for transverter operation.
IC-PW2 Dual Connection Mode
Synchronizes the operating frequency and band when
the transceiver is connected to the IC-PW2's RF input
connectors ([INPUT 1] and [INPUT 2]).
• OFF: Not synchronized with the IC-PW2.
• ON: Synchronized with the IC-PW2.
L When the IC-PW2 is not connected to the transceiver, BE
SURE to select "OFF." Otherwise, you cannot use some
functions, such as antenna switching.
(Default: OFF)
, even
XFC
(Default: OFF)
(Default: Auto)
(Default: 16.000 MHz)
(Default: OFF)
8-5
RTTY Mark Frequency
Selects the RTTY mark frequency.
L When the internal RTTY decoder is used, 2125 Hz is
automatically selected.
RTTY Shift Width
Selects the RTTY shift width.
L When the internal RTTY decoder is used, 170 Hz is
automatically selected.
RTTY Keying Polarity
Selects the RTTY keying polarity.
• Normal: Key open/close = Mark/Space
• Reverse: Key open/close = Space/Mark
PSK Tone Frequency
Selects the PSK tone frequency for PSK reception.
» SET > Function > SPEECH
MENU
SPEECH Language
Sets the speech language to English or Japanese.
SPEECH Speed
Sets the speech speed to Fast or Slow.
S-Level SPEECH
Turns the S-meter level announcement ON or OFF.
• OFF: The operating mode and the operating
frequency are announced when you push
.
SPEECH
• ON: The signal strength level, the operating mode,
and the operating frequency are announced
when you push
SPEECH
MODE SPEECH
Turns the operating mode announcement ON or OFF.
• OFF: The selected operating mode is not announced.
• ON: The selected operating mode is announced.
SPEECH Level
Sets the Voice Synthesizer audio output level.
(Default: 2125)
(Default: 170)
(Default: Normal)
(Default: 1500)
(Default: English)
(Default: Fast)
(Default: ON)
.
(Default: OFF)
(Default: 50%)
