Formatting; Unmounting - Icom IC-7760 Basic Manual

Formatting

Before using an SD card or USB flash drive, format it
to be used with the transceiver by doing the following
steps.
1. Open the SD CARD or USB FLASH DRIVE
screen.
» SET > SD Card
MENU
» SET > USB Flash Drive
MENU
2. Touch "Format." (Example: SD CARD)
3. Touch [YES] to start formatting.
• After formatting, returns to the SD CARD or USB
FLASH DRIVE screen.
L To cancel formatting, touch [NO].
4. To close the SD CARD or USB FLASH DRIVE
screen, push several times.
EXIT
SD CARD/USB FLASH DRIVE

Unmounting

Before you remove a card when the transceiver is ON,
be sure to electrically unmount it, as shown below.
Otherwise, the data may be corrupted or deleted.
1. Open the SD CARD or USB FLASH DRIVE
screen.
» SET > SD Card
MENU
» SET > USB Flash Drive
MENU
2. Touch "Unmount." (Example: SD CARD)
3. Touch [YES] to unmount.
• After unmounting, returns to the SD CARD or USB
FLASH DRIVE screen.
L To cancel unmounting, touch [NO].
4. Remove the card from the controller.
• Push in the card until a 'click' sounds to unlock the
card, and then pull it out.
Controller
(front panel)
Controller (rear panel)
5. To close the SD CARD or USB FLASH DRIVE
screen, push
EXIT
When the transceiver is OFF
You can remove the card starting from step 4 of the
steps described above.
6-2
Turns OFF
1 Push in
2 Pull out
Remove
several times.
6
6
