Selecting The Operating Band; D Selecting The Operating Band On The Sub Screen; D Selecting The Operating Band On The Main Screen - Icom IC-7760 Basic Manual

3
BASIC OPERATION

Selecting the operating band

D Selecting the operating band on the
Sub screen
1. Push several times to display the
SUB DISP
Keypad screen.
2. Touch a band keypad. (Example: 14)
• Displays a 14 MHz frequency.
Main screen
TIP: About the Band Stacking Register
The Band Stacking Register provides 3 memories for
each band. When you change the operating band or
the Register, the previously operated frequency and
mode are stored.
Band keypad
SUB DISP
3-3
D Selecting the operating band on the
Main screen
1. Touch the MHz digits. (Example: 21)
• Opens the BAND STACKING REGISTER screen.
2. Touch a band key. (Example: 14)
• Displays a 14 MHz frequency.
To display the Band Stacking Register contents:
z Touch the band key for 1 second.
z Touch the MHz digits for 1 second on the standby
screen.
L Touch to return to the previous screen.
