Icom IC-7760 Basic Manual page 64

8
SET MODE
Function
» SET > Function > MIC Key Customize
MENU
[UP]
[DN]
The function assignments for the [UP] and [DN] keys
on the SM-50 or HM-219 optional microphone can be
changed.
L See page 8-8 about the functions.
» SET > Function
MENU
Screen Keyboard Type
Sets the keyboard entry type to Ten-Key or Full
Keyboard.
Screen Full Keyboard Layout
Sets the on-screen keyboard layout to English,
German, or French.
Screen Capture [POWER] Switch
Assigns the Screen Capture function to
• OFF: does not act as the Screen Capture
POWER
key.
• ON: acts as the Screen Capture key.
POWER
Screen Capture Keyboard [Print Screen]
Assigns the Screen Capture function to the [Print
Screen] key on the USB keyboard.
Screen Capture Storage Media
Selects the SD card or USB flash drive to save screen
capture data.
Screen Capture File Type
Sets the file format for the Screen Capture function to
PNG or BMP.
Calibration Marker
Turns the reference frequency calibration marker ON
or OFF.
REF Adjust
Adjusts the internal reference frequency.
NOTE: The default setting of "REF Adjust" may differ
slightly, depending on each transceiver.
(Default: UP (VFO: kHz))
(Default: DOWN (VFO: kHz))
(Default: Full Keyboard)
(Default: English)
(Default: OFF)
.
POWER
(Default: OFF)
(Default: SD Card)
(Default: PNG)
(Default: OFF)
The assignable key functions for Front Key:
Function
Push to turn the VOX function in the Voice
operation modes and the Break-in function
VOX/BK-IN* in the CW mode ON or OFF.
L This function can be assigned for only
VOX/BK-IN
In the AM or CW mode
Push to automatically tune the operating
AUTOTUNE frequency to a close-by signal.
L This function can be assigned for only
AUTO TUNE
PRESET Push to open the PRESET screen.
In the SSB, AM, or FM mode
• Push to transmit the voice audio
Voice/Keyer/
recorded on the SD card once.
RTTY/PSK
• Hold down for 1 second to repeatedly
Memory 1
transmit the voice audio.
LIf the voice audio is not saved in the Voice TX
memory (T1 ~ T4), this function is disabled.
In the CW mode
Voice/Keyer/
• Push to transmit the Keyer memory
RTTY/PSK
content once.
Memory 2
• Hold down for 1 second to repeatedly
transmit the memory content.
LIf the Keyer memory content (M1 ~ M4) is not
entered, this function is disabled.
Voice/Keyer/
In the RTTY mode
RTTY/PSK
Push to transmit the RTTY memory
Memory 3
content once.
LIf the RTTY memory content (RT1 ~ RT4) is
not entered, this function is disabled.
In the PSK mode
Voice/Keyer/
Push to transmit the PSK memory content
RTTY/PSK
once.
Memory 4
LIf the PSK memory content (PT1 ~ PT4) is
not entered, this function is disabled.
* Hold down for 1 second to open its function menu.
NOTE: When you assign other than "VOX/BK-IN"
(default) to
VOX/BK-IN
does not light even if you turn ON the VOX or
Break-in function.
8-7
Description
.
.
, the indicator on
VOX/BK-IN
