ADVANCED MANUAL
HF/50 MHz TRANSCEIVER
|7760
This manual describes instructions for advanced features and
instructions.
See the BASIC MANUAL that come with the transceiver for
precautions and basic operations.
1 ADVANCED CONNECTIONS
2 ADVANCED OPERATIONS
3 SCOPE OPERATION (ADVANCED)
4 SD CARD/USB FLASH DRIVE (ADVANCED)
5 VOICE RECORDER FUNCTIONS
6 VOICE TX MEMORY FUNCTION
7 MEMORY OPERATION
8 SCANS
9 ANTENNA TUNER OPERATION (ADVANCED)
10 CLOCK AND TIMERS (ADVANCED)
11 OTHER FUNCTIONS
12 MAINTENANCE (ADVANCED)
13 UPDATING THE FIRMWARE
